TRF-45 PCB High Frequency Printed Circuit Board DK4.5 Taconic RF PCB With Gold plated 16mil 24mil 32mil 40mil 64mil Thick

Hi Everyone,
Today, we’re going to talk about a type of printed circuit board on low loss ceramic-fill PTFE: TRF-45 high frequency PCB.
TRF-45 is a new generation of low-loss, thermally-stable PCB material with Dk (Dielectric Constant) 4.5 +/- 0.15, Df (Dissipation Factor) 0.0035, Thermal Conductivity 0.43 W/m-K. It is woven-glass reinforced for enhanced dimensional-stability and coupled with Taconic's expertise in ceramic technology.
Typical Applications
Satellite radio
RFID
GPS antenna

Our high frequency PCBs are mainly built on 3 high frequency material brands: Rogers Corporation, Taconic and Wangling. Dielectric constant ranges from 2.2 to 10.2 etc.

We also have divisions of FR-4 circuit board, flexible circuits and metal core PCBs featured as prototypes, small runs to mass production. We also actively research and build such high value added PCB projects as HDI, quick turn, impedance control, heavy copper and backplane board etc. This has made our PCB products generate an effective prolongation and complementation, as well as formation of integrated products line ranging from low-end to high-end.

Our PCBs are used for a variety of purposes, including, but not limited to, computer networking, safety and surveillance, power supply, telecommunication, automotive electronics, medical apparatus and instruments, national defense and industrial equipment etc.
