Rogers 6010 high frequency PCB is a ceramic-filled PTFE material that is designed for high-performance electronic and microwave applications. It has a dielectric constant of 10.2 at 10 GHz, which makes it ideal for use in circuits that require high frequency signals. Bicheng PCB has the capability to manufacture high-quality Rogers 6010 PCBs with excellent DFM (Design for Manufacturability) capability.

One of the main features of Rogers 6010 high frequency PCB is its low loss, which is crucial for high frequency applications. It has a low dissipation factor of 0.0013 at 10 GHz, making it suitable for use in circuits that require high accuracy and stability.

Another feature of Rogers 6010 high frequency PCB is its excellent thermal stability. It has a low coefficient of thermal expansion (CTE) of 9.5 ppm/℃, which means it is highly resistant to temperature changes. This is important for circuits that are exposed to high temperatures, such as those found in aerospace and defense applications.

Rogers 6010 high frequency PCB also has a high thermal conductivity of 1.44 W/mK, which makes it an ideal choice for circuits that generate a lot of heat. Its high thermal conductivity helps to dissipate heat quickly and efficiently, ensuring the stability and reliability of the circuit.

Bicheng PCB has the expertise and capability to manufacture Rogers 6010 high frequency PCBs with tight thickness control and excellent dimensional stability. This ensures that the circuits perform consistently and accurately, even in harsh environments.

In addition to its excellent electrical and thermal properties, Rogers 6010 high frequency PCB is also flame-resistant and environmentally friendly. It has a UL 94 V-0 flame rating and is RoHS compliant, making it a safe and reliable choice for a wide range of applications.

In conclusion, Rogers 6010 high frequency PCB is an excellent choice for high-performance electronic and microwave circuits. With its low loss, excellent thermal stability, and high thermal conductivity, it offers superior performance and reliability. And with Bicheng PCB's DFM capability, customers can enjoy the benefits of this advanced material without worrying about the manufacturing process.
