Rogers 4350 PCB: A High-Frequency Material for Demanding Applications

Rogers 4350 is a high-frequency circuit board material that offers exceptional electrical performance, thermal stability, and mechanical reliability. It is designed for use in demanding applications such as high-speed digital, microwave, and RF circuits. With a dielectric constant (Dk) of 3.48 and a dissipation factor (Df) of 0.0037 at 10 GHz, Rogers 4350 is an ideal material for circuits that require high signal integrity and low loss.

Bicheng PCB is a leading supplier of high-quality Rogers 4350 PCBs. The company has extensive experience in producing PCBs for high-frequency applications, and its capabilities include:

High-Precision Manufacturing
Bicheng PCB uses advanced manufacturing techniques to produce high-precision Rogers 4350 PCBs. The company's state-of-the-art equipment and experienced technicians ensure that each PCB is produced to exacting standards, with precise tolerances and minimal variation.

Multi-layered PCBs
Bicheng PCB can manufacture multi-layered Rogers 4350 PCBs with up to 20 layers. This allows for more complex circuit designs and greater functionality in a smaller form factor. The company's multi-layered PCBs are designed to reduce signal loss and maintain signal integrity, even at high frequencies.

Surface Finishes
Bicheng PCB offers a range of surface finishes for Rogers 4350 PCBs, including immersion gold, immersion silver, and OSP (Organic Solderability Preservatives). These finishes provide excellent solderability and corrosion resistance, ensuring that the PCBs are reliable and long-lasting.

Quality Control
Bicheng PCB has a rigorous quality control process in place to ensure that each Rogers 4350 PCB meets the highest standards of quality and reliability. The company uses advanced testing equipment to perform electrical testing, impedance testing, and other critical tests to verify the performance of each PCB.

The Properties of Rogers 4350 PCB

Rogers 4350 PCB is known for its excellent electrical performance, thermal stability, and mechanical reliability. It has a dielectric constant (Dk) of 3.48 and a dissipation factor (Df) of 0.0037 at 10 GHz, which means that it has low signal loss and is suitable for high-speed data transmission.

In addition, Rogers 4350 PCB has a high glass transition temperature (Tg) of 280°C, which means that it can withstand high-temperature soldering processes without losing its mechanical or electrical properties. This makes it an ideal material for applications that require high reliability and durability.

Conclusion:

Rogers 4350 PCB is a high-frequency material that offers exceptional electrical performance, thermal stability, and mechanical reliability. Bicheng PCB is a leading provider of Rogers 4350 PCBs, with extensive experience and capabilities in producing high-quality PCBs for a wide range of high-frequency applications. With its precision manufacturing, multi-layered PCBs, surface finishes, and rigorous quality control process, Bicheng PCB is the ideal partner for companies that require high-performance Rogers 4350 PCBs.
