RT/duroid 6010 high frequency PCB Material properties and processing technology

RT/duroid 6010 high frequency PCB Material properties and processing technology

RT/duroid 6010 high frequency PCBs are ceramic-filled PTFE composites designed for electronic and microwave circuit applications requiring a high dielectric constant. They are ideal for applications such as power amplifiers, high-frequency oscillators, and filters, among others.

At Bicheng PCB, we specialize in producing high-quality RT/duroid 6010 PCBs. This capability ensures that our PCBs are manufactured to the highest standards, resulting in a superior product that meets our customers' needs.

One of the key advantages of RT/duroid 6010 PCBs is their high dielectric constant of 10.2, which is essential for enabling circuit size reduction. With a low dissipation factor of 0.0013 at 10GHz, these PCBs are ideal for use in high-frequency applications operating at X-band or below.

RT/duroid 6010 PCBs also have a tight dielectric constant and thickness control, resulting in repeatable circuit performance. They offer excellent thermal stability, with a thermal coefficient of dielectric constant (TCDk) of -140 ppm/℃, which is much lower than other materials. This makes them suitable for use in high-temperature environments.

In addition to their excellent electrical properties, RT/duroid 6010 PCBs also offer excellent mechanical properties. They have a high modulus of elasticity, which makes them resistant to warping and bending. They also have a low coefficient of thermal expansion (CTE) in the X and Y directions, which means that they are less prone to expansion and contraction when exposed to temperature changes.

At Bicheng PCB, we can manufacture RT/duroid 6010 PCBs in various types, including single-layer, double-layer, and multi-layer boards. We can also provide hybrid types to meet our customers' specific needs. Our RT/duroid 6010 PCBs have a wide range of thicknesses, from 4mil to 125mil. We offer copper weight options of 1oz, 2oz, and 3oz.

To ensure that our RT/duroid 6010 PCBs meet our customers' requirements, we use our advanced DFM capability to optimize our manufacturing process. We carefully analyze each design to identify any potential issues that could affect the performance of the PCB. We then make the necessary adjustments to ensure that the PCB meets the required specifications.

In conclusion, RT/duroid 6010 high frequency PCBs are an excellent choice for high-frequency applications requiring a high dielectric constant.
