Rogers RO4533 PCB 2-layer 1oz copper cu with Immersion Gold

Rogers RO4533 PCB 2-layer 1oz copper cu with Immersion Gold

  • Rogers RO4533 PCB 2-layer 1oz copper cu with Immersion Gold
  • Rogers RO4533 PCB 2-layer 1oz copper cu with Immersion Gold
  • Rogers RO4533 PCB 2-layer 1oz copper cu with Immersion Gold
Rogers RO4533 PCB 2-layer 1oz copper cu with Immersion Gold
Product Details:
Place of Origin: China
Brand Name: Bicheng Technologies Limited
Certification: UL
Model Number: BIC-264-V4.11
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD9.99-99.99
Packaging Details: VACUUM
Delivery Time: 10 working days
Payment Terms: T/T, Paypal
Supply Ability: 50000 PIECE PER MONTH
Contact Now
Detailed Product Description
Number Of Layers: 1 Layer Board Material: Polyimide 50µm
Board Thickness: 0.25mm Surface/Inner Layer Cu Thickness: 35 µm
Surface Finish: Immersion Gold Coverlay Colour: White
Color Of Silkscreen: None Function: 100% Pass Electrical Test

Introducing Our New High-Performance Rogers RO4533 PCB


We are excited to announce the launch of our new low-loss, high-frequency PCB made with Rogers Corporation's RO4533 laminates. This material is specifically engineered to provide excellent electrical performance for demanding RF applications.


The Roger RO4533 laminates have a dielectric constant of just 3.3 at 10GHz. This low dielectric constant enables tighter control over impedance as frequencies increase into the GHz range. Equally important, the dissipation factor is an extremely low 0.0025 at 10GHz. This means less signal loss and attenuation as waves propagate through the PCB substrate.


We use a 2-layer construction with 1 ounce copper on both the top and bottom layers. The thicker 1oz copper provides lower loss compared to standard 1/2 or 1/4 ounce copper foil. It also allows for higher current carrying capacity - a must for many RF circuits.


Specification Value
Board dimensions 185.78mm x 139.87 mm
Quantity 1 PCS
Tolerance +/- 0.15mm
Minimum Trace/Space 5/6 mils
Minimum Hole Size 0.4mm
Blind vias No
Finished board thickness 0.6mm
Finished Cu weight 1oz (1.4 mils) outer layers
Via plating thickness 20 μm
Surface finish Immersion Gold
Top Silkscreen White
Bottom Silkscreen No
Top Solder Mask Green
Bottom Solder Mask No


In between the copper layers, a 0.508mm thick core of Rogers RO4533 material provides consistent dielectric properties throughout the board. The dielectric constant stays uniform across the x, y, and z directions. This consistency helps maintain precise impedance control and signal integrity for your controlled-impedance traces.


Other key construction specifications include:

  • Board dimensions of 185.78mm x 139.87mm for consistency
  • 5/6 mil minimum trace/space for high-density designs
  • 0.4mm minimum hole diameter for ease of assembly
  • Immersion gold finish for oxidation resistance
  • IPC Class 2 fabrication for high-reliability and quality


The RO4533 material uses a thermoset resin system that is engineered for compatibility with standard PCB fabrication methods. It allows for excellent dimensional stability during etching, plating, and lamination while minimizing shrinkage or warpage. The result is higher yields and consistent performance when producing large PCB panels.


Features and Benefits:

  • Low Loss, Low Dk and low PIM response for wide range of application use
  • Thermoset resin system compatible with standard PCB fabrication
  • Excellent dimensional stability for greater yield on larger panels sizes
  • Uniform mechanical properties for maintaining mechanical form during handling
  • High thermal conductivity for improved power handling



Let us know if you have any other questions! We're happy to provide more detail about the electrical or mechanical performance factors that make our Rogers RO4533 PCBs ideal for cellular, WiMAX, microwave and other high-frequency applications. Just contact Sally Mao at
