Detailed Product Description
Thermal Conductivity: 1W/MK Dielectric Material, MCPCB Final Height Of PCB: 1.0mm ±0.1
Final Foil External: 1 Oz Surface Finish: Electroless Nickel Over Immersion Gold (ENIG)( 1 µ" Over 100 µ" Nickel)
Solder Mask Color: White,PSR400 WT02 Colour Of Component Legend: No Silkscreen Required
TEST: 100% Electrical Test Prior Shipment

Corrosion Resistance and Durability with ENIG Finish on RF PCBs


Introducing our latest offering - a high-frequency RF PCB engineered to deliver unmatched performance and reliability for your electronic devices. This double-sided PCB is crafted using advanced RO4350B material and is optimized to facilitate high-speed signal transmission with minimal signal loss.


At 135 x 135mm, this PCB boasts a copper (35um/1oz) and RO4350B (60mil) layer stackup with a 1.5oz final external foil. Marking a remarkable balance between surface mount and through-hole components, this PCB is designed to cater to a range of electronic designs, making it an incredibly versatile option.


With minimum trace and space of 11mil/12mil and a minimum/maximum hole size of 0.3/2.2mm, this PCB offers accurate component placement, facilitating precise performance. It is equipped with plated through holes (PTH) for reliable electrical connections, and is subjected to 100% electrical testing before shipment to ensure optimal performance.


The electroless nickel over immersion gold (ENIG) finish on this PCB offers excellent corrosion resistance and prolonged durability. It is UL 94-V0 approved, attesting to its flame-retardant properties, ensuring safety and stability even in high-temperature environments.


At a final height of 1.6mm ±0.16, this PCB is engineered for durability and longevity, with a tolerance of 0.002" (0.05mm) for drill placement and 0.0059" (0.15mm) for outline dimensions.


We offer worldwide service and accept a variety of artwork formats, including email files, Gerber RS-274-X, and PCBDOC. Whether you're seeking a high-frequency PCB for your next project or a reliable replacement for your current design, our RF PCB is the ultimate choice.


PCB SIZE 135 x 135mm=1PCS
BOARD TYPE High frequency PCB, RF PCB
Number of Layers Double sided PCB
Surface Mount Components YES
Through Hole Components YES
LAYER STACKUP copper ------- 35um(1oz)+PLATE
RO4350B 60mil
copper ------- 35um(1oz)+PLATE
Minimum Trace and Space: 11mil/12mil
Minimum / Maximum Holes: 0.3/2.2mm
Number of Different Holes: 5
Number of Drill Holes: 184
Number of Milled Slots: 0
Number of Internal Cutouts: 0
Impedance Control NO
Glass Epoxy: RO4350B 60mil, Tg 288℃
Final foil external: 1.5oz
Final foil internal: 0oz
Final height of PCB: 1.6mm ±0.16
Surface Finish Electroless nickel over Immersion Gold (ENIG)( 2 micoinch over 100 microinch nickel)
Solder Mask Apply To: NO
Solder Mask Color: NO
Solder Mask Type: N/A
Side of Component Legend NO
Colour of Component Legend NO
Manufacturer Name or Logo: N/A
VIA Plated Through Hole(PTH)
Outline dimension: 0.0059" (0.15mm)
Board plating: 0.0030" (0.076mm)
Drill tolerance: 0.002" (0.05mm)
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.
