Introducing our latest PCB, meticulously designed and expertly crafted to meet the most demanding quality standards. This advanced 2-layer rigid PCB showcases the exceptional performance and unwavering reliability you seek.
Crafted with precision, our PCB features Rogers RT/duroid 6002 Ceramic-filled PTFE composites, ensuring optimal signal integrity and reliability under challenging conditions. With a process DK of 2.94 at 10 GHz/23°C and a dissipation factor of 0.0012 at 10 GHz/23°C, it excels in efficiently transmitting high-frequency signals.
Built to endure, this PCB boasts a high thermal resistance (Td> 500°C) and operates flawlessly within a temperature range of -40℃ to +85℃. Its robust construction and exceptional performance make it suitable for a wide range of applications.
The stackup consists of a 35 μm copper layer on both the top and bottom, paired with RT/duroid 6002 substrate measuring 0.635 mm (25mil) in thickness. This configuration ensures optimal signal performance and durability, providing a solid foundation for your designs.
With precise dimensions of 211.74mm x 90mm (with a tolerance of +/- 0.15mm), this PCB offers ample space for component placement and precise routing. It supports a minimum trace/space of 5/5 mils and a minimum hole size of 0.35mm, enabling intricate and accurate circuitry.
Balancing durability and flexibility, this PCB has a finished board thickness of 0.76mm, with 1oz (1.4 mils) copper weight on the outer layers. The 20 μm via plating thickness ensures reliable conductivity and interconnectivity for your circuits.
Featuring an immersion gold surface finish for excellent solderability and corrosion resistance, this PCB prioritizes longevity and performance. The green solder masks on both the top and bottom provide protection and clarity for your PCB layout. While no top or bottom silkscreen is present, rest assured that each PCB undergoes a comprehensive electrical test before shipment, ensuring its functionality.
With 58 components, 176 total pads, and 190 vias, this PCB offers versatility and flexibility to accommodate a wide range of circuit designs. It complies with IPC-Class-2 standards, guaranteeing high-quality manufacturing and adherence to industry specifications.
