Rogers DiClad 527 PCB 2-layer rigid PCB with 0.035mm ED copper

Rogers DiClad 527 PCB 2-layer rigid PCB with 0.035mm ED copper

  • Rogers DiClad 527 PCB  2-layer rigid PCB with 0.035mm ED copper
  • Rogers DiClad 527 PCB  2-layer rigid PCB with 0.035mm ED copper
  • Rogers DiClad 527 PCB  2-layer rigid PCB with 0.035mm ED copper
Rogers DiClad 527 PCB  2-layer rigid PCB with 0.035mm ED copper
Product Details:
Place of Origin: CHINA
Brand Name: Bicheng Enterprise Limited
Certification: UL
Model Number: BIC-0267-V2.67
Payment & Shipping Terms:
Minimum Order Quantity: 1 PIECE
Price: USD2 .99-8.99 per piece
Packaging Details: VACUUM
Delivery Time: 8-9 WORKING DAY
Payment Terms: T/T,Paypal
Supply Ability: 50000 PIECE PER MONTH
Contact Now
Detailed Product Description
Board Material: PET 25µm Board Thickness: 0.25 Mm
Surface/Inner Layer Cu Thickness: 70 µm Surface Finish: Immersion Gold
Coverlay Colour: Black / Green Solder Mask Color Of Silkscreen: White
Function: 100% Pass Electrical Test Number Of Layers: 2

Rogers DiClad 527 laminates are revolutionizing the world of printed circuit board substrates. These advanced materials, woven with fiberglass reinforcement and based on PTFE composites, offer exceptional performance and reliability. With carefully controlled ratios of fiberglass to PTFE content, DiClad 527 laminates provide an extended range of dielectric constant (Dk) and exhibit superior dimensional stability and registration. While DiClad 527 laminates excel in many aspects, it's important to consider some potential shortcomings to make informed decisions for specific applications.



Features:

  • The outstanding features of Rogers DiClad 527 laminates are as follows:
  • Impressive DK range of 2.4 to 2.6 at 10 GHz and 1 MHz, 50% RH
  • Extremely low dissipation factor of 0.0017 at 10 GHz and 0.0010 at 1 MHz, 50% RH
  • Temperature coefficient of DK (TcDK) of -153 ppm/°C ranging from -10°C to 140°C at 10 GHz
  • Exceptionally low moisture absorption rate of 0.03%
  • Controlled coefficient of thermal expansion (CTE) in X, Y, and Z axes ensure stability



Benefits:

  • The utilization of Rogers DiClad 527 laminates brings forth a multitude of benefits, including:
  • Remarkably low loss tangent, ensuring signal integrity
  • Excellent dimensional stability for precise PCB manufacturing
  • Consistent product performance across frequency ranges
  • Highly uniform electrical properties across frequency spectrum
  • Reliable mechanical performance, ensuring long-term durability
  • Excellent resistance to chemicals and harsh environments
  • Stable DK over a wide frequency range, enabling consistent signal propagation
  • Low circuit losses at high frequencies, facilitating efficient signal transmission
  • Negligible performance drift in high humidity environments, ensuring reliable operation




Shortcomings:

While DiClad 527 laminates offer exceptional performance, it's important to consider the following potential shortcomings:

  • Cost: DiClad 527 laminates tend to be relatively expensive compared to standard PCB substrates, which can impact project budgets.
  • Processing Challenges: The unique composition of DiClad 527 laminates can present challenges during processing and fabrication, requiring specialized equipment and expertise.
  • Limited Availability: Availability of DiClad 527 laminates may be limited in certain regions, leading to longer lead times and potential supply chain issues.
  • Substrate Thickness Constraints: The recommended thickness range for DiClad 527 laminates may not always meet the specific requirements of certain applications, limiting design options.
  • Environmental Impact: The production of advanced laminates like DiClad 527 may have a higher environmental impact compared to standard PCB substrates, considering the complex manufacturing processes involved.
  • Learning Curve: Working with DiClad 527 laminates may require a learning curve for engineers and PCB designers who are not familiar with its unique characteristics.





Rogers DiClad 527 laminates offer exceptional performance, reliability, and stability for printed circuit board substrates. While they excel in many aspects, it's important to consider potential shortcomings such as cost, processing challenges, limited availability, substrate thickness constraints, environmental impact, and the learning curve associated with their usage. By carefully evaluating these factors, you can make informed decisions regarding the suitability of DiClad 527 laminates for your specific project requirements. It is recommended to consult with a professional PCB manufacturer for specific design and production considerations.
