|Place of Origin:||CHINA|
|Brand Name:||Bicheng Enterprise Limited|
|Minimum Order Quantity:||1 PIECE|
|Price:||USD2 .99-7.99 per piece|
|Delivery Time:||8-9 WORKING DAY|
|Supply Ability:||50000 PIECE PER MONTH|
|Board Material:||Polyimide 25μm + 0.3mm Stiffener Of Stainless Steel||Board Thickness:||0.20 Mm|
|Surface/Inner Layer Cu Thickness:||70 µm||Surface Finish:||Immersion Gold|
|Coverlay Colour:||Yellow||Color Of Silkscreen:||White|
|Function:||100% Pass Electrical Test||Number Of Layers:||2|
2-Layer Flex Printed Circuit Board (FPCB) Built on Polyimide for Microstrip Antenna
(Flexible printed circuits are custom-made products, the picture and parameters shown are just for reference)
This is a type of 2 Layer flexible printed circuit (FPC) built on polyimide for the application of Microstrip Antenna.
Base material: Polyimide 25μm + 0.3mm stiffener of stainless steel
Layer count: 2 layers
Type: Individual FPC
Format: 205mm x 74mm = 1 type = 1 piece
Surface finish: Immersion gold
Copper weight: Outer layer 70 μm/ Inner layer 0 μm
Solder mask / Legend: Yellow coverlay / white
Final PCB height: 0.20 mm
Standard: IPC 6012 Class 2
Packing: 100 pieces are packed for shipment.
Lead time: 10 working days
Shelf life: 6 months
Features and benefits
The end can be whole soldered;
Continuity of processing;
Delivery on time higher than 98% on-time-delivery rate;
Comprehensive equipment management and maintenance and process control;
Eligible products rate of first production: >95%
Diversified shipping method: FedEx, DHL, TNT, EMS
Keypad FPC, mobile phone module flex board, mobile phone module flex board Toy lamp strip, industrial surveying and mapping instrument, Consumer electrostatic Bracelet soft board.
General Properties of 2 Layer FCCL
|Double side adhesiveless flexible copper clad laminate (SF202)|
|Test Item||Treatment Condition||Unit||Property Date|
|IPC Standard * value||Typical Value|
|SF202 0512DT||SF202 1012DT|
|Peel Strength (90º)||A||N/mm||≥0.525||1.2||1.4|
|Folding Endurance (MIT)||R0.8 X 4.9N||Times||-||＞80||＞50|
|Thermal Stress||288℃, 20s||-||-||No delamination||No delamination|
|Chemical Resistance||After Chemical Exposure||%||≥80||＞85||＞85|
|Dielectric Constant (1MHz)||C-24/23/50||-||≤4.0||3.2||3.3|
|Dissipation Factor (1MHz)||C-24/23/50||-||≤0.01||0.007||0.008|
|Volume Resistvitiy||C-96/35/90||MΩ-cm||≥10^6||4.5 x 10^8||3.5 x 10^8|
|Surface Resistance||C-96/35/90||MΩ||≥10^5||1.5 x 10^6||2.0 x 10^6|
Structure of FPC
According to the number of layers of conductive copper foil, FPC can be divided into single layer circuit, double layer circuit, multi-layer circuit, double sided and so on.
Single-layer structure: the flexible circuit of this structure is the simplest structure of the flexible PCB. Usually the base material (dielectric substrates) + transparent rubber(adhesive) + copper foil is a set of purchased raw materials(semi-manufactures), the protective film and transparent glue are another kind of bought raw material. First, copper foil must be etched to obtain the required circuit, and the protective film should be drilled to reveal the corresponding pad. After cleaning, the two are combined by rolling. Then the exposed part of the pad electroplated gold or tin to protect. In this way, the big panel board will be ready. Generally also it’s stamped into the corresponding shape of the small circuit board. There is also no protective film directly on the copper foil, but printed resistance soldering coating, so that the cost will be lower, but the mechanical strength of the circuit board will become worse. Unless the strength requirement is not high and the price needs to be as low as possible, it is best to apply the protective film method.
Double layer structure: when the circuit is too complex to be wired, or copper foil is needed to shield the ground, it is necessary to choose a double layer or even a multilayer. The most typical difference between a multilayer and a single plate is the addition of a perforated structure to connect the layers of copper foil. The first process of transparent rubber + base material + copper foil is to make holes. Drill holes in the base material and copper foil first, clean and then plated with a certain thickness of copper. The subsequent fabrication process is almost the same as the single-layer circuit.
Double sided structure: both sides of the double sided FPC have pads, mainly used to connect other circuit boards. Although it and monolayer structure is similar, but the manufacturing process is very different. Its raw material is copper foil, protective film and transparent glue. The protective film should be drilled according to the position of the pad first, then the copper foil should be affixed, the pad and track lines should be etched and then the protective film of another drilled hole should be affixed.
