Detailed Product Description
Board Material: Aluminum PCB, MCPCB ITEQ 150℃ Board Thickness: 1.20 Mm +/-0.1
Surface Cu Thickness: 280 Um (8 Oz) Surface Finish: OSP
Solder Mask Colour: N/A Color Of Silkscreen: N/A
Function: 100% Pass Electrical Test

Introduction to Rogers RT/duroid 5880

Rogers RT/duroid 5880 is a high-performance PCB material that is designed for high-frequency applications. It is a PTFE-based composite that offers a low dielectric constant (Dk) of 2.2 and a low loss tangent (Df) of 0.0009 at 10 GHz. This makes it an ideal choice for applications that require low signal distortion and interference.



Construction details of Rogers RT/duroid 5880 PCB

The construction of Rogers RT/duroid 5880 PCB is a base copper of 35um, a dielectric of 62mil, and another base copper of 35um. The finished board thickness is 1.7mm, with a finished copper weight of 1.5 oz (2.1 mils) in all layers. The minimum trace/space is 6/6 mils, and the minimum hole size is 15 mils. The surface finish is HASL lead-free, and there is no silkscreen on top or bottom. The panelization details are as per Gerber.



Benefits of using Rogers RT/duroid 5880 PCB

There are several benefits of using Rogers RT/duroid 5880 PCB, which makes it the ultimate solution for high-frequency applications. One of the most significant advantages of this material is its low Dk and Df, which translates to high stability and low signal distortion. It also has excellent thermal stability, which makes it suitable for applications that require operation in a wide temperature range (-40℃ to +85℃). Additionally, it has a lead-free process, which improves its environmental sustainability.



Applications of Rogers RT/duroid 5880 PCB

Rogers RT/duroid 5880 PCB is suitable for various high-frequency applications, including 5G, radar, and satellite communications. It is also commonly used in aerospace and defense applications, medical devices, and test and measurement equipment. Its low Dk and Df make it an ideal choice for applications that require high-frequency signal integrity and low noise.



Comparison of Rogers RT/duroid 5880 with other PCB materials

When compared to other PCB materials, Rogers RT/duroid 5880 stands out due to its low Dk and Df. For instance, FR-4, which is a commonly used PCB material, has a Dk of around 4.5, which is relatively high compared to Rogers RT/duroid 5880. This makes it unsuitable for high-frequency applications that require low signal distortion. Therefore, Rogers RT/duroid 5880 is the perfect alternative for high-performance circuits.



Manufacturing process of Rogers RT/duroid 5880 PCB

The manufacturing process for Rogers RT/duroid 5880 PCB is similar to that of other PCB materials, with some specific considerations. For instance, it requires a controlled environment to ensure that the material properties are not affected during the manufacturing process. Additionally, the lead-free process requires specific handling to prevent contamination of the material.



Quality control of Rogers RT/duroid 5880 PCB

Quality control is crucial when manufacturing Rogers RT/duroid 5880 PCB to ensure that the final product meets the required specifications. This includes monitoring the material properties, verifying the layer stackup, and performing electrical testing to validate the impedance matching.



Testing and validation of Rogers RT/duroid 5880 PCB

Testing and validation are critical to ensure that the Rogers RT/duroid 5880 PCB performs as expected. This includes electrical testing to verify the impedance matching, signal integrity, and noise level. It is also essential to perform thermal testing to ensure that the material properties remain stable over a wide temperature range.



Conclusion: Why Rogers RT/duroid 5880 is the best choice for high-frequency applications

Rogers RT/duroid 5880 PCB is the ultimate solution for high-frequency applications due to its low Dk and Df, excellent thermal stability, and lead-free process. It offers unmatched performance and reliability for critical circuits, making it a top choice for industries such as aerospace, defense, and medical devices. By investing in Rogers RT/duroid 5880 PCB, you can maximize signal integrity and minimize noise, ensuring that your high-frequency circuits perform optimally.
