High Frequency PCB Built on 10mil(0.254mm) RO4350B With Immersion Gold

Customer Reviews
Kevin, Received and tested the boards - thanks very much. These are perfect, exactly what we needed. rgds Rich

—— Rich Rickett

Ruth, I got the PCB today, and they are just perfect. Please stay a little patience, my next order is coming soon. Kind regards from Hamburg Olaf

—— Olaf Kühnhold

Hi Natalie. It was perfect, I attach some pictures for your reference. And I send you next 2 projects to budget. Thanks a lot again

—— Seba T.

Kevin, Thanks, they were perfectly made, and work well. As promised, here are the links for my latest project, using the PCBs you manufactured for me:

—— Daniel F

I'm Online Chat Now

High Frequency PCB

  • High Precision High Frequency PCB suppliers
  • High Precision High Frequency PCB suppliers
  • High Precision High Frequency PCB suppliers
  • High Precision High Frequency PCB suppliers
  • High Precision High Frequency PCB suppliers

Introduction

Just as its name implies, high frequency is that the frequency is relatively high, generally refers to the frequency of >=300 MHz (i.e. wave length <=1m), that is, the usual radio frequency band. The electromagnetic wave of frequency >=1GHz is called microwave.



High frequency printed circuit board or microwave PCB refers to the printed circuit board made on the high frequency (microwave) substrate copper clad plate. The common types are: Double-sided board, multilayer board and mixed structure.


Mixed structure includes high performance special substrate, PP sheet + ordinary performance board and PP sheet mixed pressing board; high frequency substrate + ordinary FR4 substrate; high frequency substrate + metal base etc.



Advantages
1) The characteristic of low dielectric loss makes the signal loss at a lower level, which makes the signal transmission of the whole equipment excellent;
2) Low water absorbability influences dielectric constant and dielectric loss less at damp;
3) The temperature coefficient of dielectric constant is among the lowest of any circuit board material, making it ideal for temperature sensitive applications;
4) Stable electrical coefficient of dielectric constant;
5) Superior corrosion resistance;
6) The dielectric constant (DK) is low and stable, so the signal transmission is good without delay;



Typical frequencies for wireless applications:
* Current mobile: 0.9GHz - 2GHz
* 3G systems: 2.5GHz
* Bluetooth: 2.5GHz
* GPS: 12.6GHz
* LMDS: 24GHz and 40GHz
* Automotive: 77GHz


Market:

RFID, Wireless communications, base station and antenna, amplifier, military products, consumer electronics.

PCB Products and PCB Services
1) Material type: RO4350B, RO4003C, F4(PTFE), RF-35A2, TLA-6 etc.

2) PCB type: Double sided and multilayer PCB.
3) Hybrid of FR-4 and high freqency material combined.
4) RO4350B laminates: 10mil (0.254mm), 13.3mil (0.338mm), 20mil (0.508mm),  30mil (0.762mm), 60mil

5) RO4003C laminates: 12mil(0.305mm), 20mil(0.508mm), 32mil(0.813mm)

6) Base copper 0.5oz and 1oz
7) Solder mask most commonly used: Green and Red
8) Surface finish most commonly used:Immersion gold, copper exposure and HASL
9) Prototype, small batches run and volume production.
10) MOQ: 1PCS.

11) Door to door shipment service

High Frequency PCB Sample Introduction

High Frequency PCB Built on 10mil(0.254mm) RO4350B With Immersion Gold

China High Frequency PCB Built on 10mil(0.254mm) RO4350B With Immersion Gold Supplier

Large Image :  High Frequency PCB Built on 10mil(0.254mm) RO4350B With Immersion Gold

Product Details:

Place of Origin: China
Brand Name: Bicheng Enterprise Limited
Certification: UL
Model Number: BIC-0864-V8.64

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD30~40
Packaging Details: Vaccum
Delivery Time: 5-6 working days
Payment Terms: T/T / Paypal
Supply Ability: 45000 pieces per month
Detailed Product Description
Glass Epoxy: RO4350B Tg288℃, Er<3.66, RogersCorp Board Thick: 0.3 Mm ±0.03
Outer Copper Thick: 1 Oz Inner Copper Thick: 1 Oz
Surface Finish: Immersion Gold (51.3% ) 0.05µm Over 3µm Nickel Solder Mask Color: No Required
Colour Of Component Legend: Black TEST: 100% Electrical Test Prior Shipment

Product profile



1.1 General description


This is a type of high frequency PCB built on 10mil RO4350B substrate with Tg 280°C

for the application of WiFi Antenna. It's 0.3 mm thick with black silkscreen substrate and

immersion gold on pads. The base material is from Rogers supplying single up board.

They're fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 50 boards

are packed for shipment.



1.2 Features and benifits


A. Heat resistance, chemical resistance, impact strength and peeling strength are good.
B. Reducing signal loss in high frequency application meets the development needs of

     communication technology.
C. Tg > 280 ℃,
D. Gold has high solderability, no stressing of circuit boards and less contamination of

     PCB surface.
E. 100% tests inclusive of electrical test and AOI inspection.
F.  Meeting your printed circuit board needs from PCB prototyping to mass volume

     production.
G. Customer complaint rate: <1%
H. Great customer service;
I.   Reduce manufacturing cost from advanced equipment import, worker training and

     technology improvement and management.


1.3 Application


Gps antenna, WiFi amplifier, Relay Stations, Multicoupler


1.4 Parameter and data sheet

PCB SIZE 78 x 77 mm=1PCS
BOARD TYPE Double sided PCB
Number of Layers 2 layers
Surface Mount Components YES
Through Hole Components NO
LAYER STACKUP copper ------- 35um(1 oz)+plate TOP layer
RO4350B 0.254mm
copper ------- 35um(1 oz)+plate BOT layer
TECHNOLOGY
Minimum Trace and Space: 10 mil / - mil
Minimum / Maximum Holes: 0.4 mm / -mm
Number of Different Holes: 1
Number of Drill Holes: 2
Number of Milled Slots: 0
Number of Internal Cutouts: 0
Impedance Control: no
Number of Gold finger: 0
BOARD MATERIAL
Glass Epoxy: RO4350B Tg288℃, er<3.66, RogersCorp
Final foil external: 1 oz
Final foil internal: 1 oz
Final height of PCB: 0.3 mm ±0.03
PLATING AND COATING
Surface Finish Immersion gold (51.3% ) 0.05µm over 3µm nickel
Solder Mask Apply To: NO
Solder Mask Color: NO
Solder Mask Type: NO
CONTOUR/CUTTING Routing
MARKING
Side of Component Legend TOP
Colour of Component Legend Black
Manufacturer Name or Logo: N/A
VIA Plated through hole(PTH), minimum size 0.4mm.
FLAMIBILITY RATING UL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension: 0.0059"
Board plating: 0.0029"
Drill tolerance: 0.002"
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.
